RAMOS Optimax

Programmable display with temperature sensor

The display shows up to 8 parameters from any intelligent or virtual sensor, and measures 1 temperature.

Product introduction

The display can be programmed to display data from any intelligent or virtual sensor and display up to 8 parameters. LED indicators notify of the status of the sensor, with warnings and critical alerts showed on the display. The sensor display is powered from the smart port and measures 1 temperature point.

The display is designed to be mounted on the cabinet door, on the aisle wall, or on the datacenter room wall.

The display with the temperature sensor connects to the RAMOS Optimax or RAMOS Plus main monitoring unit.

Order code: RMS-P-ST-DSPL

Information Pour télécharger

Information

Key features

Product line name	Programmable display with temperature sensor
Included in the package	1.5 m CAT 5 patch cable
Ideal for	RAMOS Plus or RAMOS Optimax
Display	constant display of temperature from built-in sensor Blue backlight Displays up to 8 sensors in a standard rotating list, configuration via the CONTEG Pro Server web application 2x LED indicator (ORANGE – Warning and RED – Critical) Sensor status display (warning or critical status) Displayed units: °C, °F, % rh, %, V, (m)A, (k)W, (k)Wh Displays the IP address of the main device immediately after connection Displays the status of electronic handles (open/closed)
Spotřeba	45mA, 0.22W
Power	5V via smart port

Pour télécharger


Images

Taille du fichier : 127.13 kB

Téléchargé : 17. 12. 2024

Télécharger
